Mondraker Raze R Mountain Bike

Name: Mondraker Raze R Mountain Bike
Brand: Mondraker
SKU: 8435392877084
Price: 6995.0 NZD
Availability: OutOfStock

$6,995.00 NZD $8,995.00

Colour

Midnight Blue / Carrera Blue / Vortex Grey

Size

S M L XL

Quantity

Description

New for this season, the RAZE R has the same features as the CARBON version, but with a frame made of aluminium alloy. It’s so adept at climbing that that when it’s time to head downhill you’ll be stunned by its levels of shock absorption and manageability. Fun is quite simply one of the RAZE R’s greatest strengths. With 150mm of travel at the front and 130mm at the back, the RAZE R features a Fox 36 Float fork mated with a Fox Float shock; SRAM GX/SRAM NX Eagle 12-speed drivetrain; Mavic Crossmax XL wheels; SRAM G2 brakes; and ONOFF components.

Features

Frame: Raze 29 6061 Alloy Stealth Evo, 130mm travel, Forward Geometry
Rear Shock: Fox Float DPS LV EVOL Performance
Fork: Fox 36 29 Float GRIP EVOL Rhythm, 150mm
SRAM G2 R Brakes
SRAM NX Eagle 12speed
Mavic Wheelset & Maxxis Tyres

Technical Specifications

Frame - Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05
Rear shock - Fox Float DPS LV EVOL Performance, 205x57.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 25x8mm bottom bushings
Shock settings - Light compression, light rebound, air volume spacer 0.6
Fork - Fox 36 29 Float GRIP EVOL Rhythm, 150mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload
Headset - ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem - ONOFF Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar - ONOFF Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips - ONOFF Twin, 1lock-on, 135mm
Seatpost - ONOFF Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
Saddle - MDK series PU 2023
Front brake - Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake - Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever - Sram G2 R, tool-free reach adjust
Rims - Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes
Spokes - 24 straight-pull double butted spokes
Front hub - Infinity hub, Boost 15x110mm, IS 6 bolts
Rear hub - Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts
Front tire - Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Rear tire - Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Crankset - Truvativ Stylo 7k Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
Rings - 32T, CNC-machined alloy, X-SYNC 2
Bottom bracket - Sram DUB BSA, sealed bearings, 73mm
Chain - Sram NX Eagle, 12s, Powerlock
Rear derrailleur - Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers - Sram Trigger NX Eagle, 12s, X-Actuation 1:1
Casette - Sram XG-1230, 11-50T, 12s
Derailleur hanger - Sram UDH
Weight - 14.9 kg
Pedals - Not Included
